Gala marquee series are available in clear-span width of 10m, 12m, 15m, and 20m, all with a standard side height 3m. Its modular design and can be extended or decreased in 5m section. The main frameworks (upright support and roof beam)are manufactured by 4 channels in size 166x88x3mm, hard-pressed extruded Aluminium. The sidewalls and roof covers are manufactured of 850g/m2 PVC-coated polyester textile, flame retardant to DIN4102 B1, areM2. The fabric is available in block-out or translucent.
Gala marquee series are available with a complete range of accessories including sidewalls with clear windows, ground anchors, weight plate, lining, glass wall system, glass door units, ABS walling system, full clear covers& sidewalls, flooring system, and rain gutters system.
|Clear-span Width||Eave Height||Ridge Height||Bay Distance||Main Profile|
|10 m / 32.81 feet||3 m / 9.84 feet||4.85 m / 15.91 feet||5 m / 16.40 feet||166 x 88 x 3 mm (4 – channel)|
|12 m / 39.37 feet||3 m / 9.84 feet||5.16 m / 16.93 feet||5 m / 16.40 feet||166 x 88 x 3 mm (4 – channel)|
|20 m / 65.62 feet||3 m / 9.84 feet||6.55 m / 21.49 feet||5 m / 16.40 feet||166 x 88 x 3 mm (4 – channel)|
