Width: 20m - 30m
Our warehouse tents for the convenience of the construction enterprises short season, the venue provides a flexible distribution of flexible space.
Whether you need a permanent industrial application building or when the business grows, you need temporary buildings, Zhuhai Liri Structure can provide you the ideal solution. Our warehouse tents for the convenience of the construction enterprises short season, it provides a flexible distribution of flexible space. Use warehouse tents avoiding the need to increase the production of space rental, remote working, and other hidden costs.
Aluminum Warehouse Tent construction does not require a permanent foundation that can be built on almost any ground —- asphalt, concrete or grass, and so on. Tents in flexibility and economy are far superior to conventional steel structures, construction of buildings, and do not have the required land permits trouble. Because of the basic conditions require less, a cost is also low, so its maintenance is simple and inexpensive. The most critical, Liri warehouse tents modular architecture design, integrated storage tents provide a good foundation, can according to your needs for industrial applications tailored architecture.
Liri warehouse tents construction using German technology, in line with the International Building Code. Build up in accordance with operating specifications Liri storage tents construction, can withstand at least 80km / h wind. The structure can choose from 3 meters to 60 meters of any span length Infinity. Tents without any load-bearing pillars inside.
Upright Support Roof Beam
Gable Pole
Gable Pole
Gable Pole
Ridge Purlin Eave Purlin Gable Beam
Intermediate Purlin
Eave Tension Rail
Clear-span Width | Eave Height | Ridge Height | Bay Distance | Main Profile |
20 m / 65.62 feet | 5.2 m / 17.06 feet | 8.4 m / 27.56 feet | 5 m / 16.40 feet | 256 x 121 x 5 mm (4 – channel) |
25 m / 82.02 feet | 5.2 m / 17.06 feet | 9.2 m / 30.18 feet | 5 m / 16.40 feet | 300 x 120 x 5 mm (4 – channel) |
30 m / 98.43 feet | 5.2 m / 17.06 feet | 10 m / 32.81 feet | 5 m / 16.40 feet | 350 x 120 x 5 mm (4 – channel) |
